Dim to Deep Warm White EvenBright LED Flexstrip FA224M20-5M-24V-WW

Dim to Deep Warm White EvenBright LED Flexstrip FA224M20-5M-24V-WW

New Dim to Deep Warm White EvenBright LED Flex Strip adjusts Color Temperature upon dimming (No Controllers required). Requires a PWM dimmable power supply.  Smooth dimming transition between two warm white color temperatures with one dimmer. 3000K at full brightness then adjustable up to optional 2500K or 1800K based on strip selection via PWM dimming (mimics the tungsten lighting).  EvenBright™ strip packs 68 2016 SMD LEDs per foot. It allows a very even and bright light (unlike the older 5050 SMD LEDs caused spotting). In addition, The Quattro Bright series 24VDC LED strip features a high powered 2016 LED. Features coloring rendering index (CRI) of 90 or better (100 is best).

Type A Flex Strip is suitable for dry locations use and comes in 5 meters long (16.4 feet) long rolls. Ideal lighting where LED dots are not wanted to be seen when mounted in the optional Aluminum Profile.

Note: Use only with our Multi-Dim Drivers featuring PWM dimming capability. See Power Supplies section.

Designed for the lighting professional, EvenBright CCT Dimmable LED Flex Strip can be used for applications such as architectural lighting, Restaurants, Cabinet lighting and many other applications. LED Flex Strip Lighting has a 3M tape backing for easy installation. Our Flex Strips come with lead wires to enable easy connection to the Class 2 LED Power supply.

The 10mm (3/8”) wide LED Strip can be easily mounted into LED World’s Aluminum Channel profiles. Hence, Its small size and low voltage makes this lighting ideal for a wide range of applications. Strip can be cut to size by at each 14 LEDs (24VDC) intervals at marking points only.

It is recommended to use EvenBright FA224M20-5M-24V-WW LED Strip with LED World’s Aluminum profiles for better heat dissipation and longer LED life.

Note: Accessories are not included with this product. See accessories tab.


Features

Dim to Warm White using PWM dimming
3000K at full brightness then dim down to a optional 2500K or 1800K warmer white
 Choose the perfect shade of warm white light by turning a dimmer switch.
Double sided 3M tape backing, UL recognized PCBs
Ultra bright surface mount LEDs
CRI 90 or better
Epistar super bright LEDs, perfect color consistency
Smooth dimming transition between two warm white color temperatures with one dimmer
Even lighting, continuous length
Can be cut to size at marked intervals (14 LEDs apart)

Product Video

143 In stock

$143.00

Roll Length : 16.4 ft (5 meter)
Clear

Product Description

New Dim to Deep Warm White EvenBright LED Flex Strip adjusts Color Temperature upon dimming (No Controllers required). Requires a PWM dimmable power supply.  Smooth dimming transition between two warm white color temperatures with one dimmer. 3000K at full brightness then adjustable up to optional 2500K or 1800K based on strip selection via PWM dimming (mimics the tungsten lighting).  EvenBright™ strip packs 68 2016 SMD LEDs per foot. It allows a very even and bright light (unlike the older 5050 SMD LEDs caused spotting). In addition, The Quattro Bright series 24VDC LED strip features a high powered 2016 LED. Features coloring rendering index (CRI) of 90 or better (100 is best).

Type A Flex Strip is suitable for dry locations use and comes in 5 meters long (16.4 feet) long rolls. Ideal lighting where LED dots are not wanted to be seen when mounted in the optional Aluminum Profile.

Note: Use only with our Multi-Dim Drivers featuring PWM dimming capability. See Power Supplies section.

Designed for the lighting professional, EvenBright CCT Dimmable LED Flex Strip can be used for applications such as architectural lighting, Restaurants, Cabinet lighting and many other applications. LED Flex Strip Lighting has a 3M tape backing for easy installation. Our Flex Strips come with lead wires to enable easy connection to the Class 2 LED Power supply.

The 10mm (3/8”) wide LED Strip can be easily mounted into LED World’s Aluminum Channel profiles. Hence, Its small size and low voltage makes this lighting ideal for a wide range of applications. Strip can be cut to size by at each 14 LEDs (24VDC) intervals at marking points only.

It is recommended to use EvenBright FA224M20-5M-24V-WW LED Strip with LED World’s Aluminum profiles for better heat dissipation and longer LED life.

Note: Accessories are not included with this product. See accessories tab.


Features

Dim to Warm White using PWM dimming
3000K at full brightness then dim down to a optional 2500K or 1800K warmer white
 Choose the perfect shade of warm white light by turning a dimmer switch.
Double sided 3M tape backing, UL recognized PCBs
Ultra bright surface mount LEDs
CRI 90 or better
Epistar super bright LEDs, perfect color consistency
Smooth dimming transition between two warm white color temperatures with one dimmer
Even lighting, continuous length
Can be cut to size at marked intervals (14 LEDs apart)

Product Video

Technical Specifications

Watts/foot5.5 W/ft
Max Voltage24 VDC (Regulated/Class 2)
Amps/Roll3.75
Brightness530-550 Lumens / ft (30.5cm)
Roll Size5 Meters (16.4 Feet)
Light Source224pcs/meter (39.37″) 2016 SMD LED
Dimensions5000(L) x 12(W) x 1.0(H)mm (16.4′ x 0.47″ x 3/100″)
LEDs Type2016 SMD LED
CRI>90
LED Angle120°
Bend Radius4″(100mm) Max, one flat plane
Lamp Life>30,000 hours estimated average*
MountSmooth Clean Surface – burrows free (ambient temperature)
Operating Temperature-25°C ~ +40°C (-13°F ~ 104°F)
