1-800-387-4081
The new 24VDC outdoor rated Long Run Series LED Flex Strip Light FC60M28-15.2M-24V-X comes in 50ft (15.2m) length roll. Featuring 2835 SMD LED, which is 40% brighter than the 3528 LEDs. Also, it has a high lumen output of up to 90 lumens per watt. The dimmable long run LED Flex Strip Light is available in Neutral white (4200K) and Warm White (2700K and 3000K). Cut the low voltage (24VDC) LED strip at marked intervals (at each 6 LEDs). It comes in silicone jacket makes it suitable for dry and damp indoor/outdoor locations. It has a 3M tape backing for easy installation. Easily mount the LED Strip into LED World’s optional Aluminum Channel profiles. In addition, all of our Flex Strips come with 12″ (30.5cm) lead wires to be powered with our 24VDC Class 2 power supply.
Size of roll and maximum length: 15.2 meter (50 ft) roll.
LED World’s Long run series LED Strip Lighting can be used for architectural lighting, cove lighting and many other applications where long continuous run required. Also can be cut at marked intervals for custom lighting requirements.
LED Strip available in Warm White and Neutral White Color.
Note: This product requires an optional Class 2 Power Supply (not included).
Note: Accessories are not included with this product. See Accessories tab.
50ft Long 24VDC LED Flex Strip Light Features
| Continuous 50ft (15.2m) long run |
| Dimmable via LED World’s optional dimming solutions |
| Double sided 3M tape |
| Constant Brightness |
| Low power consumption and little heat produced |
| Outdoor rated Flexible LED light strips |
| Long life of high output LEDs |
| Solid state lighting |
| Super Bright 2835 SMD LEDs |
Product Description
The new 24VDC outdoor rated Long Run Series LED Flex Strip Light FC60M28-15.2M-24V-X comes in 50ft (15.2m) length roll. Featuring 2835 SMD LED, which is 40% brighter than the 3528 LEDs. Also, it has a high lumen output of up to 90 lumens per watt. The dimmable long run LED Flex Strip Light is available in Neutral white (4200K) and Warm White (2700K and 3000K). Cut the low voltage (24VDC) LED strip at marked intervals (at each 6 LEDs). It comes in silicone jacket makes it suitable for dry and damp indoor/outdoor locations. It has a 3M tape backing for easy installation. Easily mount the LED Strip into LED World’s optional Aluminum Channel profiles. In addition, all of our Flex Strips come with 12″ (30.5cm) lead wires to be powered with our 24VDC Class 2 power supply.
Size of roll and maximum length: 15.2 meter (50 ft) roll.
LED World’s Long run series LED Strip Lighting can be used for architectural lighting, cove lighting and many other applications where long continuous run required. Also can be cut at marked intervals for custom lighting requirements.
LED Strip available in Warm White and Neutral White Color.
Note: This product requires an optional Class 2 Power Supply (not included).
Note: Accessories are not included with this product. See Accessories tab.
50ft Long 24VDC LED Flex Strip Light Features
| Continuous 50ft (15.2m) long run |
| Dimmable via LED World’s optional dimming solutions |
| Double sided 3M tape |
| Constant Brightness |
| Low power consumption and little heat produced |
| Outdoor rated Flexible LED light strips |
| Long life of high output LEDs |
| Solid state lighting |
| Super Bright 2835 SMD LEDs |
Technical Specifications
| Watt foot | 1.5 W/ft |
| Max Voltage | 24 VDC (regulated) |
| AMPs/Roll | 3.19 Amps |
| Brightness | 130-140 Lumens / ft |
| Roll Size | 15.2 Meters (50 feet) |
| Light Source | 60pcs/meter (39.37″) 2835 SMD LED |
| Dimensions | 15200(L) x 10(W) x 1(H)mm (50′ x 25/64″ x 0.03″) |
| Max Length | 15.2 Meters (50 feet) |
| LED Angle | 120° |
| Lamp Life | >40,000 hours estimated average* |
| IP Rating | IP68 Type C |
| Mount | Smooth Clean Surface – burrows free (ambient temperature) |
| Operating Temperature | -25°C ~ +40°C (-13°F ~ +104°F) |
| Certifications | cULus listed |
Dimmable LED Drivers
30W 24VDC Class 2 Triac/0-10V Dimmable LED Driver MD-024-030VTDHV2
| Max Continuous Load | 30 W |
| Voltage | 24 VDC Output / 100~277 VAC Input |
| Power Supply Type | Regulated Class 2 (Indoor/Outdoor use) |
60W 24VDC Class 2 Triac/0-10V Dimmable LED Driver MD-024-060VTDHV2
| Max Continuous Load | 60 W |
| Voltage | 24 VDC Output / 100~277 VAC Input |
| Power Supply Type | Regulated Class 2 (Indoor/Outdoor use) |
96W 24VDC Class 2 Triac/0-10V Dimmable LED Driver MD-024-096VTDHV2
| Max Continuous Load | 96 W |
| Voltage | 24 VDC Output / 100~277 VAC Input |
| Rated Current | 4A |
| Power Supply Type | Regulated Class 2 (Indoor/Outdoor use) |
192W 24VDC Class 2 Triac/0-10V Dimmable LED Driver MD-024-192VTD52JV2
| Max Continuous Load | 192W (2 Tap x 96W) |
| Voltage | 24 VDC Output / 100~277 VAC Input |
| Rated Current | 2 x 4A |
| Power Supply Type | Regulated Class 2 (Indoor/Outdoor use) |
288W 24VDC Class 2 Triac/0-10V Dimmable LED Driver MD-024-288VTD52JV2
| Max Continuous Load | 288W (3 Tap x 96W) |
| Voltage | 24 VDC Output / 100~277 VAC Input |
| Rated Current | 3 x 4A |
| Power Supply Type | Regulated Class 2 (Indoor/Outdoor use) |
Regulated LED Drivers
100W 24VDC Class 2 DMX LED Driver LW-24100-5C-ADJ
| Max Continuous Load | 100 W |
| Voltage | 24 VDC Output / 100~277 VAC Input |
| Rated Current | 4.16A |
| Power Supply Type | DMX512 Class 2 (Indoor/Outdoor use) |
96W 24VDC Class 2 LED Power Supply with Plug
| Max Continuous Load | 96 W (77 W continuous) |
| Voltage | 24 VDC Output / 120 VAC Input |
| Power Supply Type | Regulated Class 2 (Indoor use) |
Aluminum Channel
Aluminum Channel Standard AC-1707
| Available Lengths | 1 meter(3.28ft), 2 meter(6.56ft) |
| Size | 17.5mm (0.68″) x 7mm (0.27″) |
| Included Items | Opaque lens, Mounting clip pair, End cap pair |
Wide Standard Aluminum Channel AC-2310
| Available Lengths | 1 meter (3.28ft), 2 meter (6.56ft) |
| Size | 23.5mm (0.92″) x 11mm (0.43″) |
| Included Items | Opaque lens, Mounting clip pair, End cap pair |
Corner Round Aluminum Channel AC-LA01
| Available Lengths | 1 meter (3.28ft), 2 meter(6.56ft) |
| Size | W 16mm (0.62″) x H 16mm (0.62″) |
| Included Items | Opaque lens, Mounting clip pair, End cap pair |
Corner Cove Aluminum LED Profile AC-3030G
| Lengths | 1 meter (3.28ft), 2 meter (6.56ft) |
| Included Items | Opaque lens, Mounting clip pair, End cap pair |
Aluminum Recessed Channel AC-AR1-1M
| Length | 1 meter (3.28ft) |
| Size | 17.1mm x 8.6mm (0.67″ x 0.33″) |
| Included Items | Opaque lens, End cap pair |
Drywall Aluminum LED Channel AC-501520-2M
| Lengths | 2 meter (6.56ft) |
| Included Items | Opaque lens |
Round Aluminum LED Channel AC-R008
| Lengths | 1 meter (3.28ft), 2 meter (6.56ft) |
| Size | ø 20.8mm |
| Included Items | Opaque lens, Mounting clip pair, End cap pair |
Product Accessories
WAGO 221-412 Splicing Connector
WAGO’s 221-412 COMPACT Splicing Connector is 40 % smaller than the 222 Series. Accommodate 2-wire connections with stranded wires from 0.14 to 4 mm², as well as solid and fine-stranded wires from 0.2 to 4 mm² (24–12 AWG).
WAGO 221-413 Splicing Connector
WAGO’s 221-413 COMPACT Splicing Connector is 40 % smaller than the 222 Series. Accommodate 3-wire connections with stranded wires from 0.14 to 4 mm², as well as solid and fine-stranded wires from 0.2 to 4 mm² (24–12 AWG).
WAGO 221-415 Splicing Connector
WAGO’s 221-415 COMPACT Splicing Connector is 40 % smaller than the 222 Series. Accommodate 5-wire connections with stranded wires from 0.14 to 4 mm², as well as solid and fine-stranded wires from 0.2 to 4 mm² (24–12 AWG).
H05-415 Wago Cable Connector
Low voltage cable connector with 4 terminals lever clamps to connect wire to DC male end 2.1 x 5.5mm
H05 Power Connector
Low voltage 20″ DC connector with one 2.1 x 5.5mm DC Plug Female at one end and two pigtail wires, red (+) and black (-) at the other end.
LED Low Voltage Mini Dimmer DIM-2430A
| Max Voltage | 12V~24VDC (Class 2 regulated) |
| Output | 1 channel 30-Amps (peak) |
| Dimension | L 86 x W 60 x H 35 mm (3.46″ L x 2.36″ W x 1.37″ H) |
| Brightness | 0% to 100% |
