60W Constant Current Custom Programmable Class 2 Driver AFLEX-60W-1400-S-LA

60W Constant Current  Custom Programmable Class 2 Driver AFLEX-60W-1400-S-LA

The AFlex Series of Constant Current Programmable LED Drivers offers high efficiency, smooth flicker-free dimming and Dim to off capability. Current programmable driver enables full flexibility to configure the drivers output current, dimming curve, dim-to-off, NTC settings and more.

60W Constant current driver allows output current programming in a 100-1400mA range.

We Program the driver based upon output current requirement. The auxiliary output provides power source for sensors and/or cooling devices and eliminates the need for an additional power supply. The Drivers wide operating window, dimming performance and programming options gives luminaire manufacturers a high level of flexibility.

Note: Product purchase requires a current (in mA) value to program on Class 2 Power Supply.


Features

Compliant with Title 24 Requirements
0-10V Dimmable – Dim Down to 0.1%
Dim To Off Capability
NTC – LED Temperature Sensor
Auxiliary Power Output
Wide Operating Window
CLO (Constant Lumen Output)
Up to 90% Efficiency
Universal Input Voltage
UL Listed 8750, Class 2, Class P
89

$89.00

Clear Selection

Product Description

The AFlex Series of Constant Current Programmable LED Drivers offers high efficiency, smooth flicker-free dimming and Dim to off capability. Current programmable driver enables full flexibility to configure the drivers output current, dimming curve, dim-to-off, NTC settings and more.

60W Constant current driver allows output current programming in a 100-1400mA range.

We Program the driver based upon output current requirement. The auxiliary output provides power source for sensors and/or cooling devices and eliminates the need for an additional power supply. The Drivers wide operating window, dimming performance and programming options gives luminaire manufacturers a high level of flexibility.

Note: Product purchase requires a current (in mA) value to program on Class 2 Power Supply.


Features

Compliant with Title 24 Requirements
0-10V Dimmable – Dim Down to 0.1%
Dim To Off Capability
NTC – LED Temperature Sensor
Auxiliary Power Output
Wide Operating Window
CLO (Constant Lumen Output)
Up to 90% Efficiency
Universal Input Voltage
UL Listed 8750, Class 2, Class P

Technical Specifications

IP RatingIP21 (Indoor dry location use)

Rated Power60W
Output Voltage3-57VDC
Input Voltage120-277 VAC/VDC
Programmable Output Current 100-1400mA
Dimming Control0-10V
Efficiency> 90%
Power Factor>0.95
THD<20%
